35000 BTU 4 Zone 22.5 SEER2 Ducted Mini Split AC, White

Experience discreet, multi-zone comfort with this 35000 BTU concealed ducted mini split system. It provides efficient heating and cooling across four independent zones, featuring inverter technology for energy savings, R454B refrigerant, and smart WiFi control for year-round climate management in homes and light commercial spaces.

Overview:

• Provides powerful and balanced heating and cooling across 4 independent zones for optimal comfort in various rooms.
• Designed for versatile use in homes, offices, restaurants, and other light commercial spaces.
• Features a concealed, ducted design that keeps the installation neat and discreet, blending into your space.
• Note: Professional installation is required for safe and proper setup.

Highlights:

• Adjust temperature independently across 4 zones for personalized comfort control.
• Inverter technology maintains steadier temperatures with smarter, more efficient energy use.
• R454B refrigerant supports responsible, forward-looking environmental operation.
• Built-in versatility with 7 modes and 8 fan speeds for all-season climate control.
• Enjoy peaceful sleep without distractions with dedicated sleep mode and screen off function.
• Effortless convenience with multiple smart control options including WiFi, app, and voice commands.
• Chassis electrical heating ensures reliable performance in colder conditions down to -25°C.
• 4D auto swing function for balanced and even air distribution throughout the room.
• Self-clean function makes maintenance simple and helps keep air paths fresh.
• 24-hour timer allows for set-and-forget scheduling of operation.
• Child lock feature helps prevent unwanted changes to settings.

Features:

• Multi-zone climate control providing powerful heating and cooling across 4 independent zones.
• Advanced inverter technology maintains steady temperatures with less energy waste, reducing cycling.
• 22.5 SEER2 rating for high energy efficiency and significant cost savings.
• R454B refrigerant for environmentally responsible operation.
• Chassis electrical heating ensures reliable operation in tough weather with -25°C low ambient heating and 55°C high ambient cooling.
• WiFi enabled for smart control via included remote, wall thermostat, smart app, or voice commands (compatible with Alexa and Google Assistant).
• 7 operating modes: auto, cool, heat, dry, fan, ECO, and sleep.
• 8 adjustable fan speeds for precise comfort customization.
• 4D auto swing improves room coverage and ensures even air distribution.
• Self-clean function helps keep internal air paths fresher over time with minimal maintenance.
• 24-hour timer for scheduled operation and energy management.
• Child lock keeps settings secure from unauthorized changes.
• Quiet operation with indoor unit noise levels as low as 28 dB for a peaceful environment.
• Ideal for household and light commercial use, including living rooms, bedrooms, offices, and restaurants.
• Note: Professional installation is required for safe and proper setup.

Weight & Dimensions:

• Indoor Unit Dimensions (9K model): 27.56 inches long x 17.8 inches wide x 7.87 inches high (70 cm x 45.2 cm x 20 cm).
• Indoor Unit Dimensions (12K model): 27.56 inches long x 17.8 inches wide x 7.87 inches high (70 cm x 45.2 cm x 20 cm).
• Indoor Unit Dimensions (18K model): 36.22 inches long x 17.8 inches wide x 7.87 inches high (92 cm x 45.2 cm x 20 cm).
• Indoor Unit Dimensions (24K model): 43.31 inches long x 17.8 inches wide x 7.87 inches high (110 cm x 45.2 cm x 20 cm).
• Outdoor Unit Dimensions (18K model): 36.5 inches long x 14.96 inches wide x 27.52 inches high (92.7 cm x 38 cm x 69.9 cm).
• Outdoor Unit Dimensions (27K model): 38.5 inches long x 16.57 inches wide x 31.61 inches high (97.8 cm x 42.1 cm x 80.3 cm).
• Outdoor Unit Dimensions (35K model): 42.28 inches long x 18.43 inches wide x 33.58 inches high (107.4 cm x 46.8 cm x 85.3 cm).
• Net Weight of 9K Indoor Unit: 33.1 pounds (15 kg).
• Net Weight of 12K Indoor Unit: 33.1 pounds (15 kg).
• Net Weight of 18K Indoor Unit: 39.7 pounds (18 kg).
• Net Weight of 24K Indoor Unit: 50.7 pounds (23 kg).
• Net Weight of 18K Outdoor Unit: 92.6 pounds (42 kg).
• Net Weight of 27K Outdoor Unit: 119 pounds (54 kg).
• Net Weight of 35K Outdoor Unit: 145.5 pounds (66 kg).
• Diameter of Liquid Pipe: 1/4 inch (0.64 cm).
• Diameter of Gas Pipe (9K model): 3/8 inch (0.95 cm).
• Diameter of Gas Pipe (12K model): 3/8 inch (0.95 cm).
• Diameter of Gas Pipe (18K model): 1/2 inch (1.27 cm).
• Diameter of Gas Pipe (24K model): 5/8 inch (1.59 cm).

Specifications:

• Color: White.
• Material: Cold-rolled Steel Sheet, Copper, Aluminum.
• Multi Zone Combination: 4 zones.
• Voltage: 208-230V.
• Frequency: 60Hz.
• Temperature Setting Range: 16°C to 31°C (61°F to 88°F).
• Refrigerant: R454B.
• Indoor Unit Noise Level: As low as 28 dB.
• Maximum Remote Control Distance: 39.2 feet (12 meters).
• Coverage Area for 9K model: 450 square feet (42 square meters).
• Coverage Area for 12K model: 750 square feet (70 square meters).
• Coverage Area for 18K model: 1250 square feet (116 square meters).
• Coverage Area for 24K model: 1500 square feet (139 square meters).
• Dehumidification Capacity for 9K model: 55.8 pints per day (26.4 liters per day).
• Dehumidification Capacity for 12K model: 81.2 pints per day (38.4 liters per day).
• Dehumidification Capacity for 18K model: 111.6 pints per day (52.8 liters per day).
• Dehumidification Capacity for 24K model: 131.9 pints per day (62.4 liters per day).
• Maximum Air Flow Volume for 9K model: 335 CFM (570 m³/h).
• Maximum Air Flow Volume for 12K model: 360 CFM (610 m³/h).
• Maximum Air Flow Volume for 18K model: 500 CFM (850 m³/h).
• Maximum Air Flow Volume for 24K model: 741 CFM (1260 m³/h).
• SEER2 Rating for 18K model: 24.
• SEER2 Rating for 27K model: 24.
• SEER2 Rating for 35K model: 22.5.
• HSPF2 Rating for 18K model: 10.5.
• HSPF2 Rating for 27K model: 10.5.
• HSPF2 Rating for 35K model: 10.

Package Includes:

• 1 x Outdoor Unit.
• 4 x Indoor Unit.
• 4 x Copper Connection Pipe - Gas Pipe.
• 4 x Copper Connection Pipe - Liquid Pipe.
• 4 x Communication Wire.
• 4 x Drain Hose.
• 4 x Remote Control & Holder.
• 4 x Wall Sleeve.
• 8 x Wall Cap.
• 8 x Tape.
• 8 x Putty.
• 4 x Screw Kit.
• 4 x Mounting Foot Pad.
• 9 x User Guide.

Package Quantity: 1
